Wgb is widely used in self-mobile equipment ,such as engineer machinery ,lifting machinery ,road machinery vehicles,construction machinery ,convey machinery ,agricultural machinery ,mine machinery ,sweeping&cleaning machinery,wood machinery and winches .
Specifications:
WGB300 With BMSS 250 motor’s :
| WGB300 | 5.75 | 4.6 | 3.28 | |
| Specification Motor | Motor BMSY-WT 250 | 252 | 252 | 252 |
| Pressure drop Mpa | 15.3 | 15.3 | 15.3 | |
| flow L/Min | 95.0 | 95.0 | 95.6 | |
| torque N.m | 521.7 | 521.7 | 518.3 | |
| speed rpm | 346.8 | 346.8 | 349.1 | |
| Output speed rpm | 60.3 | 75.4 | 106.4 | |
| Output torque N.m | 3000 | 2400 | 1700 | |
| Output power Kw | 18 | 18 | 18 | |
Characteristic features:
* Adopt special sealing system. Special design of composite sealing, being used in the radial and axial sealing in & between
rotating and fixed parts;
* Adopt built-in multi-disk parking brake system which is also the spring-load parking brake ,hydraulic pressure releases brake
force; on the condition that the pressure of hydraulic system decreases lower than the required pressure of the release brake, it will
safely stop rotation completely.
* Compact structure, easy mounting.
* To be preemptively used together with BMR, BMS series hydraulic orbital motors.
